Smart Version A4 UV Printer
- Model: F23V4
- Weight: 38.00kg
- Dimensions: 65.00cm x 58.00cm x 47.00cm
- Location: $1400-1800
Payment terms: Bank transfer and any available options
Lead time: 3-5 working days
MOQ: 1pcs
Compact Industrial A4 UV Printer for Smart Custom Printing
The Smart Version A4 UV Printer (model F23V4) combines industrial-grade printing technology with a compact design, ideal for studios, home-based businesses, and retail shops. Featuring advanced UV technology typically seen in larger models, this machine ensures consistent and high-quality printing across diverse materials. Designed for long-term reliability, it meets the needs of businesses seeking reduced downtime and enhanced efficiency.
With its innovative features, this A4 UV printer offers a cost-effective solution for producing professional-grade outputs with flawless precision. From small-scale promotional items to intricate designs on rigid and semi-flexible substrates, this printer elevates your business potential and return on investment.
The F23V4 A4 UV Printer stands out as a versatile tool for entrepreneurs and print shops aiming to expand their service offerings. Whether you're producing vivid images, embossed textures, or UV DTF transfers, this printer delivers exceptional results while maintaining low operational costs.
Key Features
- Compact and Space-Saving Design: With a true A4-sized platform (200×300 mm), this printer fits elegantly on desktops and counters without compromising performance.
- Industrial-Grade Durability: Crafted with a robust metal frame and vibration-free enclosure, ensuring long-term stability and reliability.
- Advanced Ink Workflow: Features an automatic white ink circulation system to prevent clogging and maintain flawless operations.
- High-Efficiency Cooling: Equipped with an advanced wind cooling system to extend the lifespan of core components.
- Precision Material Handling: Integrated servo-driven lifting tray with an aluminum vacuum bed to hold flexible or irregular objects securely during printing.
- Seamless Maintenance: Includes an industrial-grade capping station and auto print-head flashing to simplify cleaning and reduce manual upkeep.
- Multi-Effect Printing Capabilities: Supports full-color printing, white ink layering, embossed output, and UV-DTF designs, enhancing creative possibilities.
Specifications
| Specifications | Technical Details |
|---|---|
| Model Number | F23V4 |
| Printhead Configuration | Epson TX800 / XP600 |
| Print Technology | Smart Bi-directional Printing, Auto Nozzle Checking & Cleaning System, Variable Ink Droplet Technology |
| Nozzle Configuration | 1440 Nozzles (720 Nozzles x 2) |
| Maximum Print Resolution | Up to 5760x1440 dpi |
| Ink Consumption | Ultra-low Consumption: ~1.5ml per A4 size text / ~4.0ml per A4 size full-color image |
| Compatible Ink | Premium UV-curable Ink |
| Color Configuration | CMYK + 2 White |
| Platform / Tray Size | 200 x 300 mm with Aluminum Vacuum Platform |
| Maximum Print Area | 200 x 300 mm |
| Max Media Thickness | 75 mm with Full Auto Height Detection |
| Print Speed | ~12 minutes per A4-size full-color image |
| Ink Delivery System | Continuous Ink Supply System (CISS) with White Ink Stirring |
| Software | Acro RIP 10.3 (or latest versions) Professional Color Management Software |
| Cooling System | Advanced Wind Cooling System |
| Operation & Control | Fully Automatic Height Adjustment, Smart Printhead Protection, and Automated Tray Movement |
| Data Interface | High-Speed USB 2.0 / 1.1 / 3.0 Compatible Port |
| Supported OS | Windows 7 / 8 / 10 / 11 (32-bit & 64-bit Compatible) |
| Working Environment | 15-30 °C (59-86 °F), 40-70% Humidity, Dust-Free |
| Power Requirements | AC 110/220 V, 50/60 Hz, Energy-Efficient |
| Warranty & Support | 12-Month Manufacturer Warranty with Lifetime Technical Support |
| Dimensions (L x W x H) | Printer: 540 x 380 x 330 mm, Packaging: 610 x 450 x 390 mm |
| Weight | Net Weight: 21 kg, Gross Weight: 28 kg |
| Applications | Rigid Substrates, Phone Cases, Mugs, PVC, Acrylic, Leather Products, Customized Gifts |
Applications & Industry Potential
Perfect for small to medium businesses, the F23V4 A4 UV Printer allows you to tap into various markets, including personalized gift shops, promotional product vendors, and design studios. Its ability to print on diverse rigid and semi-flexible materials opens doors to customized product offerings, such as phone cases, acrylic displays, leather-bound journals, and unique merchandise.
The printer’s user-friendly operation, combined with professional-grade precision, ensures high returns on investment for businesses looking to expand into custom printing. Its robustness and compact design make it suitable for startups and established enterprises alike.
